Allison Transmission

Actual product may vary from image shown.

Allison Transmission

Stock: Ask for Lead Time
Model: Allison Transmission

Product Views: 7904

Based on 1 reviews. - Write a review

$0.00

Option

I would like to get a quote on a

Model

Serial Number

Serial Number from Previous Transmission (optional)

Core Exchange

Torque Converter

Use

Does your Transmission have a PTO provision?

Qty

Add to Wish List Compare this Product

Item #	Model	Maximun Input Power (HP)	Maximun Input Speed (RPM)	Maximun Net Input Torque (lb-ft)	Approx. Length (in)	Approx. Width (in)	Approx. Height (in)	Approx. Weight (lbs)
1	4500 OFS	565	2300	1650	34			968
2	4700 OFS	600	2300	1850	44.2			1224
3	9817 OFS	1750	2300	5250	56.5	35.3	39.8	3790
4	9823 OFS	2350	2300	6300	56.5	35.3	39.8	3790
5	9826 OFS	2600	2300	7750	56.5	35.3	39.8	3890
6	AT 545	235	3200	445	27	21	19	289
7	CL(B)T 5860-2	525	2500	1350	57	26	14	2200
8	CL(B)T 6061-2	675	2500	2100	54	26	14	2200
9	CLBT 5860 DB	433	2500	1195	57	26	40	2750
10	CLBT 5960	485	2500	1350	53	26	31	2100
11	CLBT 5960 DB	485	2500	1350	57	25	40	2750
12	CLBT 6061	615	2500	1800	57	25	40	2100
13	CLBT 6062	850	2500					2900
14	CLBT 6063	850	2500					2900
15	CLBT 750	425	2500	1300	52	22	27	1675
16	CLBT 750 DB	425	2500	1300	54	22	37	1675
17	CLT 5860	525	2500	1350	61	29	18	2800
18	CLT 5860 DB	433	2500	1195	57	26	40	2750
19	CLT 5860-5	525	2500	1350	57	26	14	2200
20	CLT 5960	550	2500	1950	61	29	18	2750
21	CLT 5960 DB	550	2500	1950	61	29	18	2750
22	CLT 5960-5	550	2500	1950	57	26	14	2750
23	CLT 6061	615	2500	1800	57	26	40	2900
24	CLT 6061-5	675	2500	2100	54	26	14	2750
25	CLT 6062	850	2500					2900
26	CLT 6063	850	2500					2900
27	CLT 750	425	2500	1300	52	22	27	1675
28	CLT(B) T5960-2	550	2500	1950	58	29	18	2750
29	CRT 3331	70	3000	375	47		39	955
30	DP 8961 (Automatic Electric)	1104	2300	3300	71	33	45	3700
31	DP 8961 (Manual Electric)	1104	2300	3300	71	33	45	3700
32	DP 8962 (Automatic Electric)	1104	2300	3300	72	36	39	3700
33	DP 8962 (Manual Electric)	1104	2300	3300	60	35	15	3700
34	DP 8963 (Automatic Electric)	1104	2300	3300	60	35	15	3700
35	DP 8963 (Manual Electric)	1104	2300	3300	60	35	15	3700
36	H 5620	600	2500	1750	43	29	31	2200
37	H 6620	975	2500	3000	43	27	31	2200
38	HT 740 DR	425	2400	1300	37	22	26	1175
39	HT 750 DRD	425	2400	1300	41	23	26	1175
40	HT 750 DB	425	2400	1300	41	22	26	1175
41	HT 750 WET DRD	425	2400	1300	41	23	26	1175
42	M5600A – DB	534	2500	1575	61	29	18	2200
43	M5600H – DB	534	2500	1575	61	29	18	2200
44	M5610A – DB	534	2500	1575	61	29	18	2200
45	M5610H – DB	534	2500	1575	61	29	18	2200
46	M 5620	600	2500	1750	43	29	31	2200
47	M 5620A-DB	600	2500	1875	61	29	14	2200
48	M 5620H-DB	600	2500	1875	61	29	14	2200
49	M 6600 (Automatic Electric Controls)	850	2500	2300	58	29	14	2200
50	M 6600 (Hydraulic)	850	2500	2300	58	29	14	2200
51	M 6600 (Manual Electric)	850	2500	2300	58	29	14	2200
52	M 6600 (Manual)	850	2500	2300	58	29	14	2200
53	M 6610 (Automatic Electric Controls)	850	2500	2300	58	29	14	2200
54	M 6610 (Hydraulic)	850	2500	2300	58	29	14	2200
55	M 6610 (Manual Electric)	850	2500	2300	58	29	14	2200
56	M 6610 (Manual)	850	2500	2300	58	29	14	2200
57	M 6620	900	2500	2750	58	29	14	2200
58	M 6620 (Automatic Electric Controls)	900	2500	2750	58	29	14	2200
59	M 6620 (Hydraulic)	900	2500	2750	58	29	14	2200
60	M 6620 (Manual Electric)	900	2500	2750	58	29	14	2200
61	M 6620 (Manual)	900	2500	2750	58	29	14	2200
62	M 8610	1104	2300	3300	55	35	35	3700
63	M 9610	2500	2300	3700	57	45	57	3700
64	MT-643	250	4000	585	31	19	22	478
65	MT-644	250	3000	780	31	19	22	562
66	MT-653DR	250	4000	585	36	19	22	564
67	MT-654	300	3000	950	36	19	22	685
68	MT-654 CR	300	3000	950	36	19	22	685
69	S 5620	625	2500	1950	43	29	31	2200
70	S 6600 (Automatic Electric Controls)	850	2500	2300	58	29	18	2200
71	S 6600 (Hydraulic)	850	2500	2300	58	29	18	2200
72	S 6600 (Manual Electric)	850	2500	2300	58	29	18	2200
73	S 6600 (Manual)	850	2500	2300	58	29	18	2200
74	S 6610 (Automatic Electric Controls)	850	2500	2300	58	29	18	2200
75	S 6610 (Hydraulic)	850	2500	2300	58	29	18	2200
76	S 6610 (Manual Electric)	850	2500	2300	58	29	18	2200
77	S 6610 (Manual)	850	2500	2300	58	29	18	2200
78	S 6620	900	2500	2750	58	29	18	2200
79	S 6620 (Automatic Electric Controls)	900	2500	2750	58	29	18	2200
80	S 6620 (Hydraulic)	900	2500	2750	58	29	18	2200
81	S 6620 (Manual Electric)	900	2500	2750	58	29	18	2200
82	S 6620 (Manual)	900	2500	2750	58	29	18	2200
83	S 8610A (Automatic Electric)	1104	2300	3300	60	35	19	3700
84	S 8610A (Manual Electric)	1104	2300	3300	60	35	19	3700
85	S 8610M	1104	2300	3300	60	35	19	3700
86	S 9800	2250	2100	6100	60	35	19	3700
87	S 9810	2250	2100	6100	60	35	19	3700
