-01-550x550.jpg "Showing image for Sealbore Hydraulic Permanent Packer")
Actual product may vary from image shown.
Sealbore Hydraulic Permanent Packer
- Stock: Ask for Lead Time
- Model: Hydraulic Permanent Packer
Product Views: 7367
$0.00
Option
| Casing Size (in.) | Casing Weight (lbm/ft.) | Max. OD (in.) | Nominal ID (in.) | Upper Sealbore (in.) | Setting | Pressure diferencial (psi.) | Thread type (in.) |
| 4.5 | 9.5–16.6 | 3.562 | 1.937 | 2.625 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 5 | 11.5–18.0 | 4.276 | 1.937 | 2.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 5.5 | 9.0–13.0 | 4.875 | 1.937 | 2.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 5.5 | 13.0–23.0 | 4.375 | 1.937 | 2.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 6-5/8 | 17.0–24.0 | 5.375 | 2.375 | 3.500 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 6-5/8 | 24.0–32.0 | 5.375 | 2.875 | 3.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 7 | 17.0–32.0 | 5.875 | 2.500 | 3.500 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 7 | 17.0–32.0 | 5.875 | 2.875 | 3.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 7 | 17.0–32.0 | 5.875 | 3.375 | 4.250 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 7 | 23.0–32.0 | 5.875 | 3.937 | 4.690 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 7-5/8 | 20.0–39.0 | 6.375 | 2.375 | 3.500 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 7-5/8 | 20.0–39.0 | 6.375 | 2.875 | 3.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 8-5/8 | 24.0–49.0 | 7.250 | 3.875 | 5.375 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 9-5/8 | 29.3–58.4 | 8.187 | 2.875 | 3.750 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 9-5/8 | 29.3–58.4 | 8.187 | 3.875 | 5.375 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 9-5/8 | 29.3–58.4 | 8.187 | 4.750 | 6.000 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
| 9-5/8 | 47 | 8.187 | 6.000 | 7.250 | Hydraulic | 6,000 | 2-7/8 ; 3-1/2 (Specify) |
