Actual product may vary from image shown.
Hydro-Brake / Hydromatic Style
- Stock: Ask for Lead Time
- Model: Hydro-Brake
Product Views: 7407
$0.00
Option
| Size | Maximum Pressure P.S.I | Maximum Speed R.P.M | Maximum Shaft Dia. Inches | Volume In Gallons | Weight Of Brake Pound | Capacity Horse Power |
| 15" D. R. | 25 | 2300 | 3 1/8 | 6 | 580 | 1600 |
| 121 | 25 | 2300 | 3 1/8 | 2 | 300 | 800 |
| 122 | 25 | 2300 | 3 1/8 | 3 1/4 | 432 | 1600 |
| 22" S. R. | 25 | 1550 | 4 15/16 | 10 | 1200 | 2500 |
| 201 | 25 | 1550 | 5 | 5 | 980 | 1500 |
| 202 | 25 | 1550 | 5 | 9 1/10 | 1475 | 3000 |
| 22" D. R. | 25 | 1550 | 4 15/16 | 20 | 2300 | 4000 |
| V80 | 15 | 1550 | 5 | 13 1/2 | 1240 | 5000 |
| S. S. R. 28 | 15 | 900 | 5 | 17 | 2120 | 5500 |
| 262 | 15 | 850 | 5 1/2 | 30 | 2750 | 6000 |
| 341 | 15 | 600 | 7 1/2 | 35 | 3400 | 6000 |
| 341A | 15 | 600 | 7 1/2 | 35 | 2465 | 6000 |
| 342 | 15 | 600 | 7 1/2 | 56 | 5300 | 7500 |
| 342A | 15 | 600 | 7 1/2 | 56 | 3900 | 7500 |
| 60" S. R. | 15 | 375 | 7 1/2 | 180 | 9500 | 8000 |
| 451 | 15 | 500 | 7 1/2 | 78 | 3700 | 8500 |
| 481 | 15 | 450 | 7 1/2 | 98 | 7500 | 9000 |
| V200 | 15 | 480 | 7 1/2 | 96 | 9100 | 10000 |
| V295 | 15 | 350 | 9 1/4 | 315 | 26880 | 12000 |
