40 CN Series

Applications: Compressor Lube Oil. Off-line Filter Loops. Machine Tools (Automotive Standard). Hydrostatic Drive Charge Pumps. Mobile Equipment. Pilot Lines For Servo Controls. Oil Patch Drilling Equipment. Injection Molding. This partial list of applications for Parker “CN” series filters has a common factor, the need for an economical, medium pressure range filter with excellent fatigue pressure ratings. Prior to the availability of the “CN” filter, applications such as those listed were restricted by limitations of a spin-on can, or forced into the higher cost range of high pressure filters. The “CN” series fills this gap, and now with the newly increased fatigue rating from 550 to 800 psi, the applications are expanded. Features: 800 psi fatigue rating (eight times that of a spin-on). Diametral (side) seal between head and bowl. Dust Seal. Cast aluminum head. Standard Ecoglass III elements. Complete performance data disclosure. Visual, electrical or electrical/visual indicators available.

Product Details
Bypass	K - 50 PSI (3.5 bar)
Element Length	2 - Double
Indicator	H - Electrical indicator with ½”-14 NPT connection and 12” leads
Media Code	02QE - Ecoglass III, 2 micron
Element Collapse Rating	150 psi (10.3 bar)
Options	4 - Standard drain port on bowl
Seals	B - Nitrile (NBR)
Note	40CN
Filter Series	40CN - In line Filter
Ports	N16 - 1” NPT
Design Safety Factor	2.5:1
Operating Temperatures	Nitrile: -40°F (-40°C) to 225°F (107°C)
Pressure Ratings Rated Fatigue Pressure:	800 psi (55.2 bar)
Pressure Ratings Maximum Allowable Operating Pressure (MAOP):	1000 psi (69 bar)
Shipping Weights (approximate)	Double length - 5.5 lb. (2.49 kg)
Element Condition Indicators	Visual 360° green/red auto reset Electrical/Visual 5A @ 240VAC, 3A @ 28VDC
