Buy P3 High Pressure/Super Charged Mobile Piston Pumps |Denison Piston Pumps Tools

P3 Piston Pumps are ideal for open circuit mobile applications with high self priming speed and operating pressure up to 4650 PSI (320 BAR). These high performance pumps are suited for mobile applications where inlet fill characteristics are not ideal; i.e. high altitudes, long inlet lines, cold weather and high pump drive speeds. Benefits/Features: Compact. Low noise level. Sealed shaft bearing. Service friendly. Reliable. Long-lasting. Flexible. Easy to install. High self-priming speed.

Product Details
Mounting Flange	C - SAE C 2/4-Bolt
A Max* Dimensions	12.89 (327.5)
G Dimensions	5.87 (150)
Port Location	A - Side Flanges, UNC
Seal Type	N - Nitrile, single shaft seal
Controls	TD(3) - Torque/LS/Pmax with bleed orifice, Torque range 50-90% of max
D Dimensions	4.41 (112)
F Dimensions	7.17 (182)
B Max. Dimensions	0.49 (12.5)
E Max. Dimensions	8.26 (210)
C Max. Dimensions	2.98 (75.6)
Rotation*	L - Left (CCW)
Displacement in3/rev (cm3/rev)	105 - 6.4 (105)
Percent of Max. Displacement	00 - 100% Stroke, standard factory setting
Differential Pressure Setting	20 - Recommended Initial Factory Setting
Torque Control Setting	71 - 20-90% of Max. Rated Torque(3)
Thru-drive	B2 - SAE B – 2-Bolt with SAE BB Spline
Paint Option	P - Parker Black
Multiple Pumps Option	1 - Single Pump
Pump Series	P3
Pressure Compensator Setting1 Factory set in bar times 10; Range	27 = 270 bar setting
Shaft Options	C1 - SAE C Spline
