Wireline Retrievable Injection Pressure Operated Gas Lift Valve

Actual product may vary from image shown.

Wireline Retrievable Injection Pressure Operated Gas Lift Valve

Product Views: 1787

Based on 0 reviews. - Write a review

$0.00

Valve OD (in.)

Port Size (in.)

Seat Type

Qty

							Material Standard Services
Valve OD (in.)	Ab= Effective Bellows Area (in2)	Port Size (in.)	Ap= Area of Port (in2)	Ap/Ab Ratio (in2)	1-(Ap/Ab)	PPEF Ap/Ab 1-(Ap/Ab)	Bellows	Seat	Bellows Connections	Pressure Rating (psi.)	Temperature Rating (F)
1	0.31	1/8	0.014	0.044	0.956	0.046	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1	0.31	5/32	0.021	0.067	0.933	0.072	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1	0.31	3/16	0.029	0.095	0.905	0.105	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1	0.31	1/4	0.052	0.166	0.834	0.199	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1	0.31	5/16	0.080	0.257	0.743	0.346	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1-1/2	0.31	3/16	0.029	0.038	0.962	0.040	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1-1/2	0.77	1/4	0.052	0.067	0.933	0.072	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1-1/2	0.77	5/16	0.080	0.104	0.896	0.115	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1-1/2	0.77	3/8	0.114	0.148	0.800	0.174	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1-1/2	0.77	7/16	0.154	0.200	0.739	0.250	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250
1-1/2	0.77	1/2	0.201	0.261	0.632	0.353	Specify	Replaceable floating Monel or Tungsten carbide	Silver-brazed	1.800	250

Wireline Retrievable Injection Pressure Operated Gas Lift Valve
