Completion Tubing

Actual product may vary from image shown.

Completion Tubing

Stock: Ask for Lead Time
Model: Completion Tubing

Product Views: 1375

Based on 0 reviews. - Write a review

$0.00

Option

Tubing Size (in.)

Tubing Grade

Qty

Add to Wish List Compare this Product

Tubing size (in.)	OD (in.)	Nominal Weight (lb/ft.)		Grade	Wall thickness (in.)	Inside Diameter (in.)	Drift (in.)	Threaded coupling			Colapse resistance (psi.)	Internal yield pressure (psi.)	Joint yield strength
		T and C Non-upset (lb/ft.)	T and C upset (lbs/ft)					Coupling outside diameter					T and C Non-upset (lbs.)	T and C upset (lbs.)
		T and C Non-upset (lb/ft.)	T and C upset (lbs/ft)					Non-Upset (in.)	Upset regular (in.)	Upset special (in.)			T and C Non-upset (lbs.)	T and C upset (lbs.)
3/4	1.05	1.14	1.20	H-40	0.113	0.824	0.730	1.313	1.660		7,200	7,530	6,360	13,300
3/4	1.05	1.14	1.20	J-55	0.113	0.824	0.730	1.313	1.660		9,370	10,360	8,740	18,290
3/4	1.05	1.14	1.20	C-75	0.113	0.824	0.730	1.313	1.660		12,250	14,120	11,920	24,940
3/4	1.05	1.14	1.20	N-80	0.113	0.824	0.730	1.313	1.660		12,710	15,070	12,710	26,610
1	1.315	1.700	1.800	H-40	0.113	1.049	0.955	1.660	1.900		6,280	7,080	10,960	19,760
1	1.315	1.700	1.800	J-55	0.113	1.049	0.955	1.660	1.900		8,860	9,730	15,060	27,160
1	1.315	1.700	1.800	C-75	0.113	1.049	0.955	1.660	1.900		11,590	13,270	20,540	37,040
1	1.315	1.700	1.800	N-80	0.113	1.049	0.955	1.660	1.900		12,270	14,160	21,910	39,510
1-1/4	1.660	2.300	2.400	H-40	0.125	1.410	1.286	2.054	2.200		5,220	5,270
1-1/4	1.660	2.300	2.400	H-40	0.140	1.380	1.286	2.054	2.200		5,790	5,900	15,530	26,740
1-1/4	1.660	2.300	2.400	J-55	0.125	1.410	1.286	2.054	2.200		6,790	7,250
1-1/4	1.660	2.300	2.400	J-55	0.140	1.380	1.286	2.054	2.200		7,530	8,120	21,360	36,770
1-1/4	1.660	2.300	2.400	C-75	0.140	1.380	1.286	2.054	2.200		9,840	11,070	29,120	50,140
1-1/4	1.660	2.300	2.400	N-80	0.140	1.380	1.286	2.054	2.200		10,420	11,810	31,060	53,480
1-1/2	1.900	2.750	2.900	H-40	0.125	1.650	1.516	2.200	2.500		4,450
1-1/2	1.900	2.750	2.900	H-40	0.145	1.610	1.516	2.200	2.500		5,290		19,090	31,980
1-1/2	1.900	2.750	2.900	J-55	0.125	1.650	1.516	2.200	2.500		5,790
1-1/2	1.900	2.750	2.900	J-55	0.145	1.610	1.516	2.200	2.500		6,870		26,250	43,970
1-1/2	1.900	2.750	2.900	C-75	0.145	1.610	1.516	2.200	2.500		8,990	10.020	35,800	59,970
1-1/2	1.900	2.750	2.900	N-80	0.145	1.610	1.516	2.200	2.500		9,520	10,680	38,180	63,960
2-1/16	2.063			H-40	0.156	1.751					5,240	5,290
2-1/16	2.063			J-55	0.156	1.751					6,820	7,280
2-1/16	2.063			C-75	0.156	1.751					8,910	9,920
2-1/16	2.063			N-80	0.156	1.751					9,440	10,590
2-3/8	2.375	4.00		H-40	0.167	2.041	1.947	2.875	3.063	2.910	4,880	4,920	30,130
2-3/8	2.375	4.60	4.70	H-40	0.190	1.995	1.901	2.875	3.063	2.910	5,520	5,600	35,960	52,170
2-3/8	2.375	4.00		J-55	0.167	2.041	1.947	2.875	3.063	2.910	6,340	6,770	41,430
2-3/8	2.375	4.60	4.70	J-55	.190	1.995	1.901	2.875	3.063	2.910	7,180	7,700	49,450	71,730
2-3/8	2.375	4.00		C-75	0.167	2.041	1.947	2.875	3.063	2.910	8,150	9,230	56,500
2-3/8	2.375	4.60	4.70	C-75	0.190	1.995	1.901	2.875	3.063	2.910	9,380	10,500	67,430	97,820
2-3/8	2.375	5.80	5.95	C-75	0.254	1.867	1.773	2.875	3.063	2.910	12,180	14,040	96,560	126,940
2-3/8	2.375	4.00		N-80	0.167	2.041	1.947	2.875	3.063	2.910	8,660	9,840	60,260
2-3/8	2.375	4.60	4.70	N-80	0.190	1.995	1.901	2.875	3.063	2.910	9,940	11,200	71,930	104,340
2-3/8	2.375	5.80	5.95	N-80	0.254	1.867	1.773	2.875	3.063	2.910	12,890	14,970	102,990	135,400
2-3/8	2.375	4.60	4.70	P-105	0.190	1.995	1.901	2.875	3.063	2.910	13,250	14,700	94,410	136,940
2-3/8	2.375	5.80	5.95	P-105	0.256	1.867	1.773	2.875	3.063	2.910	17,190	19,650	135,180	177,710
2-7/8	2.875	6.40	6.50	H-40	0.217	2.441	2.347	3.500	3.668	3.460	5,230	5,280	52,780	72,480
2-7/8	2.875	6.40	6.50	J-55	0.217	2.441	2.347	3.500	3.668	3.460	6,800	7,260	72,580	99,660
2-7/8	2.875	6.40	6.50	C-75	0.217	2.441	2.347	3.500	3.668	3.460	,900	9,910	98,970	135,900
2-7/8	2.875	860	8.70	C-75	0.308	2.259	2.165	3.500	3.668	3.460	12,200	14,060	149,360	185,290
2-7/8	2.875	6.40	6.50	N-80	0.217	2.441	2.347	3.500	3.668	3.460	9,420	10,570	105,570	144,960
2-7/8	2.875	8.60	8.70	N-80	0.308	2.259	2.165	3.500	3.668	3.460	12,920	15,000	159,310	198,710
2-7/8	2.875	6.40	6.50	P-105	0.217	2.441	2.347	3.500	3.668	3.460	12,560	13,870	138,560	190,260
2-7/8	2.875	8.60	8.70	P-105	0.308	2.259	2.165	3.500	3.668	3.460	17,220	19,690	209,100	260,810
3-1/2	3.500	7.70		H-40	0.216	3.068	2.943	4.250	4.500	4.180	4,070	4,320	65,070
3-1/2	3.500	9.20	9.30	H-40	0.254	2.992	2.867	4.250	4.500	4.180	5,050	5,080	79,540	103,610
3-1/2	3.500	10.20		H-40	0.289	2.922	2.797	4.250	4.500	4.180	5,680	5,780	92,550
3-1/2	3.500	7.70		J-55	0.216	3.068	2.943	4.250	4.500	4.180	5,290	5,940	89,470
3-1/2	3.500	9.20	9.30	J-55	0.254	2.992	2.867	4.250	4.500	4.180	6,560	6,980	109,370	142,460
3-1/2	3.500	10.20		J-55	0.289	2.922	2.797	4.250	4.500	4.180	7,390	7,950	127,250
3-1/2	3.500	7.70		C-75	0.216	3.068	2.943	4.250	4.500	4.180	6,690	8,100	122,010
3-1/2	3.500	9.20	9.30	C-75	0.254	2.992	2.867	4.250	4.500	4.180	8,530	9,520	149,140	194,260
3-1/2	3.500	10.20		C-75	0.289	2.922	2.797	4.250	4.500	4.180	9,660	10,840	173,530
3-1/2	3.500	12.70	12.95	C-75	0.375	2.750	2.625	4.250	4.500	4.180	12,200	14,060	230,990	276,120
3-1/2	3.500	7.70		N-80	0.216	3.068	2.943	4.250	4.500	4.180	7,080	8,640	130,140
3-1/2	3.500	9.20	9.30	N-80	0.254	2.992	2.867	4.250	4.500	4.180	9,080	10,160	159,090	207,220
3-1/2	3.500	10.20		N-80	0.289	2.922	2.797	4.250	4.500	4.180	10,230	11,560	185,100
3-1/2	3.500	12.70	12.95	N-80	0.375	2.750	2.625	4.250	4.500	4.180	12,920	15,000	246,390	294,530
3-1/2	3.500	9.20	9.30	P-105	0.254	2.992	2.867	4.250	4.500	4.180	12,110	13,330	208,800	271,970
3-1/2	3.500	12.70	12.95	P-105	0.375	2.750	2.625	4.250	4.500	4.180	17,200	19,690	323,390	386,570
4-1/2	4.500	12.60	12.75	H-40	0.271	3.958	3.833	5.200	5.563		3,930	4,220	104,360	144,020
4-1/2	4.500	12.60	12.75	J-55	0.271	3.958	3.833	5.200	5.563		5,100	5,800	143,500	198,030
4-1/2	4.500	12.60	12.75	C-75	0.271	3.958	3.833	5.200	5.563		6,430	7,900	195,680	270,240
4-1/2	4.500	12.60	12.75	N-80	0.271	3.958	3.833	5.200	5.563		6,810	8,430	208,730	288,040
