Actual product may vary from image shown.
High-Rated SealBore Hydraulic-Coiled Tubing Packer Hydraulic-Coiled Tubing Packer
- Stock: Ask for Lead Time
- Model: Hydraulic-Coiled Tubing Packer
Product Views: 5416
$0.00
Option
| Casing Size (in.) | Casing Weight (lbm/ft) | Casing ID Min. (in.) | Casing ID Max. (in.) | Tool size (in.) | Tool OD Max. (in.) | Standard Tool Sealbore (in.) | Setting | Type | Temperature °F | Slips | Pressure diferencial (psi.) | Thread type (in.) |
| 7 | 26.00–32.00 | 6,094 | 6,276 | 58–40 | 5,870 | 4,000 | Hydraulic or coiled tubing | Permanent | 350 | Double | 10,000 | Premiun ; (Specify) |
| 7 | 17.00–20.00 | 6,456 | 6,538 | 61–40 | 6,182 | 4,000 | Hydraulic or coiled tubing | Permanent | 350 | Double | 10,000 | Premiun ; (Specify) |
| 9-5/8 | 47.00–58.40 | 8,435 | 8,681 | 82–60 | 8,218 | 6,000 | Hydraulic or coiled tubing | Permanent | 350 | Double | 10,000 | Premiun ; (Specify) |
| 9-5/8 | 36.00–47.00 | 8,681 | 8,921 | 84–60 | 8,432 | 6,000 | Hydraulic or coiled tubing | Permanent | 350 | Double | 10,000 | Premiun ; (Specify) |
