Actual product may vary from image shown.
Lifting Sub
- Stock: Ask for Lead Time
- Model: Lifting Sub
Product Views: 8573
$0.00
Option
| Item # | Drill Collar OD (in) | ID (in) | Length (in) | Approx. Weight (lbs) | Connection | |
|---|---|---|---|---|---|---|
| 1 | 2-7/8" | 1-1/4" | Specify | Specify | NC23 | |
| 2 | 2-7/8" | 1-3/4" | Specify | Specify | 2-3/8" IF Pin Down | |
| 3 | 3-1/2" | 1-1/2" | 36" | Specify | 2-3/8" IF Pin Down | |
| 4 | 3-1/2" | 2-1/8" | Specify | Specify | 2-7/8" IF Pin Down | |
| 5 | 3-1/2" | 2" | Specify | NC35 | ||
| 6 | 3-1/2" | 2-5/7" | Specify | Specify | 3-1/2" IF Pin Down | |
| 7 | 4-1/8" | 2" | 36" | Specify | 2-7/8" IF Pin Down | |
| 8 | 4-3/4" | 2-1/4" | 36" | Specify | 3-1/2" IF Pin Down | |
| 9 | 4-3/4" | 2-1/4" | 36" | 105 | 3-1/2" API IF Pin Down | |
| 10 | 4-3/4" | 2-1/4" | 42" | 240 | 3-1/2" API IF Pin Down | |
| 11 | 5" | 2-1/4" | 36" | Specify | 3-1/2" IF Pin Down | |
| 12 | 5" | 2-4/5" | Specify | Specify | NC44 | |
| 13 | 5" | 3-1/4" | Specify | Specify | 4" IF Pin Down (NC46) | |
| 14 | 5" | 3-1/4" | Specify | Specify | 4-1/2 IF (NC50) | |
| 15 | 5" | 3-1/4" | Specify | Specify | NC56 | |
| 16 | 5" | 3-3/4" | Specify | Specify | 6-5/8" Reg. Pin Down | |
| 17 | 5" | 3-3/4" | Specify | Specify | NC61 | |
| 18 | 5" | 3-3/4" | Specify | Specify | 7-5/8" Reg. Pin Down | |
| 19 | 5" | 3-3/4" | Specify | Specify | NC70 | |
| 20 | 5" | 3-3/4" | Specify | Specify | NC77 | |
| 21 | 6-1/2" | 2-13/16" | 36" | Specify | 4-1/2" XH Pin Down | |
| 22 | 6-1/2" | 2-13/16" | 36" | Specify | 4-1/2" IF Pin Down | |
| 23 | 6-1/2" | 2-13/16" | 36" | Specify | 4-1/2" XH Pin Down | |
| 24 | 6-1/2" | 2-13/16" | 36" | Specify | 4-1/2" IF Pin Down | |
| 25 | 6-1/2" | 2-13/16" | 36" | 300 | 4-1/2" IF Pin Down | |
| 26 | 6-1/2" | 2-13/16" | 42" | 350 | 4-1/2" IF Pin Down | |
| 27 | 6-3/4" | 2-13/16" | 36" | Specify | 4-1/2" IF Pin Down | |
| 28 | 7" | 2-13/16" | 36" | Specify | 5-1/2" FH Pin Down | |
| 29 | 7" | 2-13/16" | 36" | Specify | 5-1/2" FH Pin Down | |
| 30 | 8" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 31 | 8" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 32 | 8" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 33 | 8" | 2-13/16" | 36" | 400 | 6-5/8" Reg. Pin Down | |
| 34 | 8" | 2-13/16" | 42" | 400 | 6-5/8" Reg. Pin Down | |
| 35 | 8-1/4" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 36 | 8-1/4" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 37 | 8-1/2" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 38 | 8-1/2" | 2-13/16" | 36" | Specify | 6-5/8" Reg. Pin Down | |
| 39 | 9-1/2" | 3" | 36" | Specify | 7-5/8" Reg. Pin Down | |
| 40 | 9-1/2" | 3" | 36" | Specify | 7-5/8" Reg. Pin Down | |
| 41 | 9-1/2" | 3" | 36" | 500 | 7-5/8" Reg. Pin Down | |
| 42 | 9-1/2" | 3" | 42" | 500 | 7-5/8" Reg. Pin Down | |
| 43 | Other (As Specify By Customer) | |||||
