Actual product may vary from image shown.
Side Entry Sub
- Stock: Ask for Lead Time
- Model: Side Entry Sub
Product Views: 1214
$0.00
Option
| Item # | OD Body (in) | Length (in) | WP (Psi) | Connection | Union Type | |
|---|---|---|---|---|---|---|
| 1 | 4-3/4" | 30" | F/10M | 3-1/2" IF Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 2 | 4-3/4" | 36" | Specify | 3-1/2" IF Box x Pin Welded 2" | Fig. 1502 Female Thread Half Side Entry | |
| 3 | 4-7/8" | 30" | Specify | 3-1/2" IF Box Up x Pin Down | Fig. 1502 Female Thread Half Side Entry | |
| 4 | 5" | 30" | F/10M | 3-1/2" IF Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 5 | 5" | 30" | F/10M | XT39 Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 6 | 5-1/2" | 30" | F/10M | 4 FH Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 7 | 6-1/2" | 32" | F/10M | 4-1/2 XH Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 8 | 6-1/2" | 32" | F/10M | 4-1/2 IF Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 9 | 6-1/2" | 30" | Specify | 4-1/2 IF Box Up x Pin Down | Fig. 1502 Female Thread Half Side Entry | |
| 10 | 6-1/2" | 36" | Specify | 4-1/2" IF Box x Pin Welded 2" | Fig. 1502 Female Thread Half Side Entry | |
| 11 | 6-3/4" | 36" | F/10M | XT54 Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 12 | 6-5/8" | 32" | F/10M | 4-1/2 IF Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 13 | 7" | 36" | F/10M | HT55 Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 14 | 7" | 34" | Specify | 5-1/2" FH Box Up x Pin Down | Fig. 1502 Female Thread Half Side Entry | |
| 15 | 7-1/4" | 36" | F/10M | 5-1/2" FH Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 16 | 7-1/4" | 36" | F/10M | XT57 Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 17 | 7-1/4" | 36" | Specify | XT57 Box Up x Pin Down | Fig. 1502 Female Thread Half Side Entry | |
| 18 | 8" | 41" | Specify | 6-5/8 FH Box Up x Pin Down | Fig. 1502 Female Thread Half Side Entry | |
| 19 | 8-1/4" | 36" | F/10M | 6-5/8 FH Box Up x Pin Down | Fig. 1502 Female Side Outlet | |
| 20 | Other (As Specify By Customer) | |||||
