Series BV3D
Door to Door International Shipping
Ships from U.S.A.
- Stock:
- Brand: Parker
- Model: Series BV3D
- MPN: BV3D12B1SS1NA
Product Views: 1069
$581.79
Series BV3D is a 3-way diverter. The product is rated at 207 Bar (3000 PSI) and designed to economically satisfy many 3-way applications. Features: The standard L-bore ball and T-bore option allows the valve to be utilized in a variety of applications. Slight port overlap reduces upstream shock during shifting. Utilizing the unique spindle thrust bearing design reduces actuation torque. The BV3D can be panel mounted which allows a variety of installation options. Delrin seals with molybdenum disulphide (MoS2) results in lower actuation torque and will increase high duty life cycle expectancy.
| Product Details | |
| Size | 12 - 3/4" |
| Body Material | S - Steel |
| Series | BV3D |
| Ball Pattern | 1 - L-Bore Port Overlap |
| Ball and Stem Material | S - Steel |
| Ball Seals | 1 - Delrin |
| Maximum pressure | 207 Bar (3000 PSI) |
| Shaft Seals | N - Nitrile |
| Ports | B - BSPP Thread |
| Standard Handle | Steel Offset, Nickel Plated |
| Weights - kg (lbs.) | 12 - 1.9 (4.25) |
| Temperature Range with Standard Seals | -30°C to +100°C (-22°F to +212°F) |
| Thread (inches) | M27 x 2 |
