Double-acting air hydraulic cylinder is something that has become very popular since they are pneumatically controlled cylinders that are designed to generate higher hydraulic pressures. With these higher pressures, one can achieve greater stroke force than it is attained using only pneumatic cylinders.


Here, in this blog, we are going to share with you some use cases of these  Double-Acting Air Hydraulic cylinders. Before we jump right into discussing the use cases, you must know that these  Double-Acting Air Hydraulic cylinders are readily available at any hydraulic parts shop near you. The shops selling oilfield supplies, oilfield tools, or drilling rigs usually also sell these  Double-Acting Air Hydraulic Cylinders. So, if you are looking for one, or get convinced to use one after reading this blog, be assured that you can find it easily online.

But the question that comes to mind now is what is the difference between a single and  Double-Acting Air Hydraulic Cylinder?


Before getting to its applications, let’s dive into some major differences between single and  Double-Action Air Hydraulic Cylinders. It is quite evident from their names that a single action cylinder will produce thrust the moves load in just a single direction, unlike the double-action cylinder. The double-action cylinder is known to offer thrust in two directions and therefore can push the load up and down or back and forth. This is one of the major differences between the single and double action pneumatic cylinder. You will also find a common porting at each end of double action cylinders which allows the compressed air to enter from one end to push and the other end to pull. This simple mechanism is what makes a double-action cylinder work in two directions.


Apart from this, the difference also lies in the complexity of the operation of these cylinders. The single-action cylinder is quite simple in comparison to the double-action cylinders but at the same time, they are quite slow when compared to the double-action ones. Another thing to note here is that the doubt-action hydraulic cylinders are great for repetitive actions in which single-action cylinders fail.


Coming back to the point.


Let’s discuss the -

List of applications of  Double-Acting Air Hydraulic Cylinder

Before the discovery of these double-action pneumatic cylinders, people usually used two single-action cylinders to offer push and pull motion. However, after the discovery of these double-action cylinders, it has become much more convenient. Using these double-action cylinders improves the overall efficiency and makes the process go much faster. There are two basic types of these  Double-Acting Air Hydraulic cylinders which are rodless cylinders and cable cylinders. You can choose either one depending on your requirements.

Industrial Applications

We all know that these  Double-Acting Air Hydraulic cylinders are expensive since they are much better than single-action cylinders. These double-action cylinders are known for their better strength and speed. Moreover, they are also known to consume lesser energy for the same job in comparison to the single-action cylinders which makes them much more effective for industrial use. Some of these industrial use cases include -


  • Opening and closing valves and doors

  • Taking or putting things off conveyor belts

  • Lifting the merchandise and moving it around

  • Silk Screening

  • Knifing

  • Pressing and Punching

  • Medical Equipment

  • Opening and kissing doors and gates


These are a few examples of how these  Double-Acting Air Hydraulic Cylinders can be put to industrial use.

Robotics Uses

Another field where you can use these Double-Acting Air Hydraulic Cylinders is robotics. These pneumatic cylinders have been a part of robotics since the introduction of McKinney artificial muscle. Since then, more and more robotic companies and industries have been finding different ways of using these cylinders and improving their inventions.

These Double-Acting Air Hydraulic Cylinders are quite versatile and can be used for several different industrial purposes as well as non-industrial purposes.

Some non-industrial applications of these Double action Air Hydraulic Cylinders include elevators, forklifts, suspension systems for cars as well as other vehicles including aeroplanes, drilling, Earth-moving, construction businesses, log-splitters, and car transport carriers.

These are some non-industrial use cases of these  Double-Action Air Hydraulic Cylinders. By now we are sure that you have understood how these pneumatic cylinders are so much better than the single-action ones.

Conclusion

In the end, we would like to say that these Double-Action Air Hydraulic Cylinders have become quite useful in almost all industries and because it has become so popular, they can be easily found in any of the online oilfield tools shop or industrial equipment shops in general. Before you hit the market looking for these double-action cylinders, you should make sure that you know the type of cylinder you want and why.

At Drilling Parts, you will find all types of Double-Acting Air Hydraulic cylinders along with power tong drilling rigs, oilfield supplies, and hydraulic parts. Drilling parts has become a go-to solution for all those who are in search of industrial supplies. Along with the guarantee of quality, they also provide timely deliveries which makes them even more reliable.
