Mechanical Set Anchor
- Stock: Ask for Lead Time
- Model: Mechanical Set Anchor
Product Views: 7198
$0.00
Option
| Casing | Tool | Thread Connection Box up/pin down (in.) EUE | |||
| Size (in.) | Weight (lbs.) | Hole Size (in.) | OD (in.) | ID (in.) | |
| 4-1/2 | 9.5 | 3.920 | 3.750 | 1.94 | 2-3/8 |
| 4-1/2 | 13.5 | 4.090 | 3.750 | 1.94 | 2-3/8 |
| 5-1/2 | 13.0 | 4.778 | 4.500 | 2.0 | 2-3/8 |
| 5-1/2 | 20.0 | 5.044 | 4.500 | 2.44 | 2-7/8 |
| 7.0 | 17.0 | 6.0 | 5.750 | 2.50 | 2-7/8 |
| 7.0 | 32.0 | 6.538 | 5.750 | 3.00 | 3-1/2 |
| 7-5/8 | 24.0 | 6.6 | 6.4 | 2.5 | 2-7/8 |
| 7-5/8 | 39.0 | 7.0 | 6.4 | 2.5 | 2-7/8 |
| 8-5/8 | 24.0 | 7.7 | 7.5 | 4.0 | 4-1/2 |
| 8-5/8 | 40.0 | 8.1 | 7.5 | 4.0 | 4-1/2 |
| 9-5/8 | 32.3 | 8.53 | 8.3 | 4.0 | 4-1/2 |
| 9-5/8 | 53.5 | 9.0 | 8.3 | 4.0 | 4-1/2 |
